B737 MAX - EFIS Module

€ 389.85
Tax excluded

EFIS Module for the Boeing 737 MAX Simulator

Quantity

Key Features

Customized Options

  • Scale 1:1
  • Plexiglass Panel 6mm thickness, laser cut & engraved
  • Metallic casing. Grey RAL 7011
  • Module fully assembled and mounted, ready to be used. Plug & Fly
  • Methacrylate Panel with 6mm thickness, laser cut & engraved.
  • Warm White LED-Backlighting.
  • Replica injection plastic Knobs.
  • Printed Circuit Board (PCB).
  • Components mounted in the PCB.
  • High quality.
  • Ready to be connected with the Sismo's MCP v4 or superior
Function Alpha Line
Front Panel high quality 6mm X
Metal casing X
IDC Interface X
Power Supply 12V X
Backlight (Warm White) X
Backlight ready for dimming X
Replica Injection Plastic Knobs X
CTR Push button X
TFC Push button X
MINS selector X
BARO selector X
Ready to be connected with MCP Ethernet X

Video

Unpacking

Replica Injection Plastic Knobs

The knobs set have been made in injection plastic following the real specifications, providing high and very real feeling.

Metallic Casing

The casing is very robust, simplify the installation in the MIP and provides a professional termination of the MCP.

Backlighted with input for dimming

The MCP includes backlight (Warm White), but if you have the Sismo´s MIP, it allows to be connected also with the MIP dimmer.

IDC parallel Bus

Ready to be connected with the MCP v4 or superior through an IDC bus.

S7MX-MCP-M-AL-A10-2020

Data sheet

Backlight
Warm White (12V)
Ready to be Connected
Yes (IDC Connectors)
Customizable
Yes
Product Lines
Alpha
Flat Ribbon Cables
Yes, 2 cables 20cm lenght. For other lenght, send email to info@sismo-soluciones.com
I/O Electronic Compatibility
SimCard Ethernet (recommended), IOCard USB, Arduino
Documentation
Datasheet
Version
V1
Measurements (WxDxH)
118 x 120 x 70 mm

Download

MX EFIS Module V1

Datasheet - B737MAX EFIS Module V1 - Rev1.0

Download (417.02KB)
